I
-
Making Measurements
Measuring AM Delay (Option 1 DA or 1
DB)
Calibrate
For
an
AM
Delay
Measurement
1. Connect the equipment
as
shown:
NETWORK
ANALYZER
1
Figure
3-l
6. Equipment Setup For an AM Delay Response Calibration
3-44
2.
Press [CAL)
Respmse
Measure
Staxxdard
.
