Front/Rear Panel
Connectors
VIDEO
OUT
COLOR
VGA
This rear panel connector provides signals to drive an external VGA
compatible monitor. The table below describes a VGA compatible monitor,
and Figure 8-6 shows the pin-out for the VIDEO OUT connector, looking into
the connector.
Table 8-2. VGA Compatible Monitor Characteristics
~~
Separate TTL signals for vertical
1 The
analper
also provides for sync-on-green monitors. See ‘Using an External VGA Monitor” in Chapter 4.
Pin
#
Signal Description
1
Red Video
2
Green Video
3
Blue Video
4
N/C
IReserved
5
GND [Monitor self-test1
View Looking Into Connector
Figure 8-6. VIDEO
OUT
Connector Pin-out
See “Using an External VGA Monitor” in Chapter 4 for information on how to
synchronize and adjust the display on an external monitor.
8-11
