I
-
I
-
Using
an
External
VGA
Monitor
The rear panel VIDEO OUT COLOR VGA connector can be connected to a
VGA compatible monitor for enhanced measurement viewing. This section
describes how to customize the color on an external VGA monitor. Refer to
Chapter 8 for more information on the VIDEO OUT COLOR VGA connector.
4-97
-1
I-
