Displaying Measurement Results
It is often helpful to eliminate unnecessary information and annotation that
might distract an operator, and only show the information necessary to
perform a particular task.
The analyzer provides several features to let you customize the information
shown on the display as shown in the following figure. Many of the features
discussed in this section can also be implemented using the analyzer’s user
interface. See “Customizing the Display” in Chapter 4 for more information.
DMeas Chan 1 info here
.Meas Chan 2 Info here.
dB
40
30
Measl: Mkrl 10.582 Sfx
-54.741
Meas2: Mb r 1 11.583
-0.06@ dB
10.500 Sfx Freq 1 Label 10.600 Sfx
11.500 SfX Frea 2 Label 11.600 Sfx
Figure 7-11. Customized Annotation
Customizing features such as limit testing, annotating the X-axis, and using
the title feature are described in this section.
