I
-
Front/Rear Panel
line Module
The
Line
Fuse
The line fuse
(HP
part number
2110-0882),
and a spare, reside within the line
module. Figure 8-12 illustrates where the fuses are and how to access them.
REWDR I VER
PRY OPEN
FUSE IN USE
SPARE FUSE
Figure
8.12.
location of line Fuses
WARNING
For continued protection against fire hazard replace line fuse only with
same type and rating (T
5A
250 V). The use of other fuses or material is
prohibited.
8-23
