HP 8711C User Manual

I
-
I
-
Using Instrument Functions
Customizing the Display
Measurement title and
The measurement title area consists of two lines of text. In the default
clock or preset state, this annotation area is toggled off. When the title
mode is initially turned on - by pressing @GG?) More Display
Title and Clock - line 1 is empty and the clock (date and time of day) is
assigned to line 2.
The TlitSe and Clock menu allows you to customize these two lines. The
clock can be shown on line 1, line 2, or can be turned off. You can enter up
to 30 characters of text on either or both lines.
When the display is in split display mode, line 1 is shown at the top of the measurement channel 1
screen, and line 2 is shown at the top of the measurement channel 2 screen.
lb turn the measurement title and clock on or off, press (DISPLAY)
Hare Display Title anct Clock Ti%le*Clk OM off.
Measurement Channel
The measurement channel annotation at the top of the display screen can
Annotation
be modilled through the use of SCPI commands. See Chapter 7 for more
information.
lb turn the measurement channel annotation on or off, press (DISPLAY)
Mom Display Annotation Options Meas Annot ON off.
Frequency Annotation The frequency annotation at the bottom of the display (X-axis) can be
modified through the use of SCPI commands. See Chapter 7 for more
information.
To turn the measurement channel annotation on or off, press (WJ
#ore Display Annotation Options Frsq Anntot ON off .
4-57
