HP 8711C User Manual

I
-
I
-
Using Instrument Functions
Connecting and Configuring Printers and Plotters
Defining a Plotter Make the following selections in the analyzer menus:
1. Press Bsstor*e Defaults to restore the default parameters for a plotter.
The defaults are:
Auto Feed
ON
Color Plotter Pen Numbers
Trace 1 - Pen 1
Trace 2 - Pen 2
Memory 1 - Pen3
Memory 2 - Pen 4
Graticule - Pen 5
Graphics - Pen 6
Default
Monochrome
2. Select the type of plotter you have: either monochrome or color.
3. Use Sst Pen NIX&Q~ to select the pen number(s) for the data traces,
memory traces, graticule, and graphics. Press Prfo~ Menu when done
selecting pens.
4. If you do not want auto feed active, press Auta Fe&d Off .
4-86
