HP 8711C User Manual

Automating Measurements
Operator Interaction
Once you have selected a menu, the same menu will be displayed
for subsequent key presses of the @?%i] hardkey. (This is not true if
your IBASIC program has changed. If your program has changed, the
User BEGIN mode is reset to OFF)
By selecting (SYSTEM OPTIONS) System Conf$g Softkey Auto-Step
User TTL Input you can automatically step through the user-defined
(BEGIN_) menu keys by use of a switch connected to the USER TTL IN/OUT
rear panel connector. See “Using User-Defined [BEGIN) with a Switch, ’ later
in this chapter for more information.
Selecting the User BEGIN softkey will run a macro function defined by a
sequence of IBASIC commands defined within an IBASIC program. IBASIC
programs to be used for User BEGIN must have the following structure:
10
20
30
40
50
60
70
80
100
110
120
140
150
160
170
200
210
!The following label must be present. DO NOT REMOVE
User-begin: !
. . .
! Define softkey labels
OUTPUT 087lX;“DISP:MENU2:KEYl ‘Test Setup l’;*WAI”
OUTPUT 087lX;“DISP:MENU2:KEY2 ‘Test Setup 2’;*WAI”
OUTPUT 0871X;“DISP:MENU2:KEY3 ‘Save Results’;*WAI”
OUTPUT 087lX;“DISP:MENU2:KEY4 ‘Print Results 4’;*WAI”
User-pause: PAUSE
GOT0 User-pause
!The following key labels must be present. DO NOT REMOVE
User,keyl:
!Insert code for softkey 1 here
GOT0 User-pause
User-key2: !Insert code for softkey 2 here
GOT0 User-pause
. . .
User,key7:
!Insert code for softkey 7 here
GOT0 User-pause
7-23
