HP 8711C User Manual

I
-
Specifications and Characteristics
Instrument Specifications and Characteristics
Determining Test Port
The maximum test port power output of your analyzer depends upon the
Power
options that are installed. If you have a standard instrument with no options
installed, then the values in the table preceding this note apply to your
analyzer. Otherwise, use the following table to determine your instrument’s
maximum test port power:
Oetion
1 HP8711C 1 HP8713C 1
1El
[Attenuator]
1EC
175 ohm]
1DA or 1DB
IAM delay1
subtract 1 dB
subtract 1 dB
subtract 3 d6
subtract 3 dB
subtract 2 dB
subtract 4 dB
For each option installed, subtract the indicated amount from the maximum
and minimum powers stated in the standard tables. For example, if you have
an HP 8713C with Options 1EC and 1DB installed, you would subtract a total
of 7 dB from the standard values found in the tables to get a final correct
maximum output of 3 dB for your analyzer, and - 12 dB for the minimum
output power. However, the minimum output power for any analyzer with
Option 1El (attenuator) is -60 dBm, regardless of other options installed.
If you are not sure which options (if any) are installed in your analyzer, press
[SYSTEM OPTIONS] Sertrico fn~s%%~~errt Ida for a display of the options
installed.
Source Harmonics (measured at +7 dBm*)
Frequency HP 871X
HP 871X
<l MHz
<-20 dBc
<-30 dBc
21 MHz
<-30 dBc <-30 dBc
” The “measured et’ value depends on your analyzer’s option configuration. Standard instruments are measured at +7dBm. Subtract the
amountfsl shown in “Determining Test Port Power’ from +7 dBm to determine the “measured at” value for your particular analyzer.
10-6
