Preset State and Memory Allocation
SOURCE Key Settings (continued)
Power level
RF power
Power sweep start power
Power sweep stop power
Trigger source
Trigger mode
Number of points
Start distance*
Stop distance*
External reference
Spur avoid options
preset power
level1
On
0.0
dBm
1.0
dBm
Internal
Continuous
201
0.00 ft
iO.00
ml
100.00
ft
130.48
ml
Off
None
1
Preset power level is user-defined by using the
Preset Pwr Level
key The factory default is 0
dBm.
2
Analyzers
with Option 100 only
CONFIGURE Key Settings
Scaleldiv
Reference level
Reference position
Reference
trackina
10
dB/div
0
dB
5
Off
