User-supplied tools and equipment
• Phillips screwdriver P1 – 100 mm, P2 – 150 mm and P3 – 250 mm
• Plain screwdriver P4 – 75 mm
• Screws with various specifications
• Meters and equipment such as HUB, terminal, and multimeter
• ESD-preventive gloves or wrist strap, ESD-preventive mat, anti-static bags
• Electric drill (for wall-mounting the router)
• Hammer
Pre-installation checklist
Table 5 Pre-installation checklist
Item Re
uirements Yes No
Installation
site
Ventilation
• There is a minimum clearance of 10 cm (3.9 in) around
the router chassis intake and exhaust vents for heat
dissipation.
• The installation site ventilation system is adequate.
Temperature 0°C to 45°C (32°F to 113°F)
Relative humidity 5% to 90% (noncondensing)
Cleanness Dust concentration ≤ 3 × 10
4
particles/m
3
ESD prevention
• The equipment and floor are properly grounded.
• The equipment room is dust-controlled.
• Humidity and temperature are maintained at proper
levels.
• Wear an ESD-preventive wrist strap when inspecting or
handling a circuit board.
• Place any removed memory module, CF card, or
interface module face-up on an antistatic workbench or
in an antistatic bag.
• Touch only the edges, not any electronic components,
when inspecting or handling a memory module, CF
card, or interface module.
EMI prevention
• Take measures to protect the power system from the
power grid system.
• Keep the protection ground of the router as far away
from the grounding device or lightning protection
grounding device as possible.
• Keep the router far away from radio transmitters, radar,
and high-frequency or high-voltage devices.
• Use electromagnetic shielding when necessary.
