HP A-MSR900 Series User Manual

2
A-MSR900-W panel views
Figure 3 A-MSR900-W front panel
(1) USB port (2) Reset button
Figure 4 A-MSR900-W rear panel
(1) Grounding screw (2) Console port (3) Ethernet WAN port ETH0
(4) Ethernet WAN port ETH1 (5) Ethernet LAN ports (ETH2 to
ETH5)
(6) Antenna port
(7) Power adapter port
A-MSR900-W(NA) panel views
Figure 5 A-MSR900-W(NA) front panel
(1) USB port (2) Reset button
