4
A-MSR920-W panel views
Figure 9 A-MSR920-W front panel
(1) USB port (2) Reset button
Figure 10 A-MSR920-W rear panel
(1) Grounding screw (2) Antenna port (3) Console port
(4) Ethernet WAN port ETH0 (5) Ethernet WAN port ETH1 (6) Ethernet LAN ports (ETH2 to
ETH5)
(7) Ethernet LAN ports (ETH6 to
ETH9)
(8) Antenna port (9) Power adapter port
A-MSR920-W(NA) panel views
Figure 11 A-MSR920-W(NA) front panel
(1) USB port (2) Reset button
