5
Figure 12 A-MSR920-W(NA) rear panel
1 2 3 4 5 6 7
8
(1) Groundin
g
screw (2) Antenna port (3) Console port
(4) Ethernet WAN port ETH0 (5) Ethernet WAN port ETH1 (6) Ethernet LAN ports (ETH2 to
ETH5)
(7) Ethernet LAN ports (ETH6 to
ETH9)
(8) Antenna port (9) Power adapter port
