48
2. Configuration on Device B
# Enable DLDP globally, configure GigabitEthernet 1/0/49 and GigabitEthernet 1/0/50 to operate in
full duplex mode and at 1000 Mbps, and then enable DLDP on the two ports.
<DeviceB> system-view
[DeviceB] dldp enable
[DeviceB] interface gigabitethernet 1/0/49
[DeviceB-GigabitEthernet1/0/49] duplex full
[DeviceB-GigabitEthernet1/0/49] speed 1000
[DeviceB-GigabitEthernet1/0/49] dldp enable
[DeviceB-GigabitEthernet1/0/49] quit
[DeviceB] interface gigabitethernet 1/0/50
[DeviceB-GigabitEthernet1/0/50] duplex full
[DeviceB-GigabitEthernet1/0/50] speed 1000
[DeviceB-GigabitEthernet1/0/50] dldp enable
[DeviceB-GigabitEthernet1/0/50] quit
# Set the DLDP mode to enhanced.
[DeviceB] dldp work-mode enhance
# Set the port shutdown mode to auto.
[DeviceB] dldp unidirectional-shutdown auto
3. Verifying the configurations
After the configurations are complete, you can use the display dldp command to display the DLDP
configuration information on ports.
# Display the DLDP configuration information on all the DLDP-enabled ports of Device A.
[DeviceA] display dldp
DLDP global status : enable
DLDP interval : 5s
DLDP work-mode : enhance
DLDP authentication-mode : none
DLDP unidirectional-shutdown : auto
DLDP delaydown-timer : 1s
The number of enabled ports is 2.
Interface GigabitEthernet1/0/49
DLDP port state : advertisement
DLDP link state : up
The neighbor number of the port is 1.
Neighbor mac address : 0023-8956-3600
Neighbor port index : 59
Neighbor state : two way
Neighbor aged time : 11
Interface GigabitEthernet1/0/50
DLDP port state : advertisement
DLDP link state : up
The neighbor number of the port is 1.
Neighbor mac address : 0023-8956-3600
