Mode Select, Mode Sense
Six-Byte Parameter Formats
The 6- byte parameter formats contains a 4- byte header followed by an optional Block
Descriptor, followed by
the requested page.
6·Byte Parameter List Header Format
Bit
Byte
7
I
6
I
5
I
4
I
3
I
2
I
1
t
00
Sense Data Length
01
Media Type = 0
02 WP
I
Reserved
I DPOFUA I
Reserved
03
Block Descriptor Length
6·Byte Block Descriptor Format (Optional)
Bit
Byte
7
J
6
I
5
I
4
I
3
I
2
I
1
J
04
Density Code = 0
05-07
(MSB=05) Number Of Blocks (LSB=07)
08
Reserved
09-11
(MSB=09)
Block Length
(LSB=l1)
Parameter List Page Format
Bit
Byte 7
6 5
I
4
I
3
I
2
I
1
I
00
PS
Reserved
Page Code
01 Page Length in Bytes
02-nn Page Parameters
Refer to the Parameter Specification Tables that follow.
0
0
0
DRAFT
SCSI Command Descriptions A·19
1/18/93 09:58
