HP c8000 User Manual

C–12 Technical Reference Guide
Cable Pin-Outs
23 AD[27] AD[26]
24 AD[25] Ground
25 +3.3V AD[24]
26 C/BE[3]# IDSEL
27 AD[23] +3.3V
28 Ground AD[22]
29 AD[21] AD[20]
30 AD[19] Ground
31 +3.3V AD[18]
32 AD[17] AD[16]
33 C/BE[2]# +3.3V
34 Ground FRAME#
35 IRDY# Ground
36 +3.3V TRDY#
37 DEVSEL# Ground
38 Ground STOP#
39 LOCK# +3.3V
40 PERR# Reserved*
41 +3.3V Reserved*
42 SERR# Ground
43 +3.3V PAR
44 C/BE[1]# AD[15]
45 AD[14] +3.3V
46 Ground AD[13]
47 AD[12] AD[11]
48 AD[10] Ground
49 M66EN AD[09]
50 Ground Ground 5 volt key
51 Ground Ground 5 volt key

HP c8000 Specifications

General

Brand	HP
Model	c8000
Category	Desktop
Language	English
