1–6 Technical Reference Guide
Product Information
Power Consumption and Cooling
This information is based on primary power consumptions.
1. A typical configuration includes: 1 CPU, 4 GB RAM (4 x 1 GB), 700W power supply, 2 hard drives, 1
medium power AGP, and 1 optical drive.
2. A maximum configuration (fully loaded) includes: 2 CPUs, 32 GB RAM (8 x 4 GB), 700W power supply,
4 hard drives, 1 high end AGP, and 3 optical drives.
Environmental Specifications
Operating temperature and humidity ranges may vary depending on the installed mass storage
devices. High humidity levels can cause improper disk operation. Low humidity levels can
aggravate static electricity problems and cause excessive wear of the disk surface.
Components Power Consumption
Workstation: typical configuration
1
410W 1399 Btu/h
maximum configuration
2
871W 2973 Btu/h
Processor 130W 443.6 Btu/h
IDE hard disk drive with I/O access 23W 78.4 Btu/h
IDE hard disk without I/O access (idle) 16W 54.5 Btu/h
PCI card 10W to 25W 34.12 Btu/h to 85.30 Btu/h
AGP card 110W maximum
(150W possible with
optional power
dongle)
170.6 Btu/h
Environmental Specifications (System Processing Unit with Hard Disk)
Operating temperature +5° C to +35° C (+41° F to +95° F)
Storage temperature -20° C to +70 C (-4° F to +158° F)
Over-temperature shutdown +38° C (+100° F)
Operating humidity 15% to 80% relative (non-condensing)
Storage humidity 8% to 80% relative (non-condensing)
Operating altitude 0 – 3000 m (0 – 10,000 ft.)
Storage altitude (long-term) 0 – 4600 m (0 – 15,000 ft.)
