Technical Reference Guide 1–1
1
Product Information
This chapter provides an overview of the HP workstation c8000, including:
■ System Features, page 1-1
■ Physical Characteristics, page 1-4
■ Power Specifications, page 1-5
■ Front Panel, page 1-7
■ Rear Panel, page 1-9
System Features
The HP workstation c8000 is available in several different configurations. To obtain more
information for your system, see one of the following:
■ Boot Console Handler (BCH) Information menu (page 2-6).
■ Features and overview at: http://www.hp.com/workstations/risc/c8000
■
Supported accessories and components at: http://partsurfer.hp.com
Feature Description
Processor One or two HP PA-8800 processor modules
Firmware 8 MB flash EEPROM
Configured using Boot Console Handler (BCH)
Operating system HP-UX 11i v1
Main memory Capacity:
• Minimum 1 GB (2 x 512 MB)
• Supports up to 32 GB (8 x 4 GB)
Type: PC2100 ECC registered DDR266 DIMMs
Slots: Eight DIMM slots
Peak bandwidth: up to 8.5 GB/sec
For memory loading order and detailed memory installation instructions,
see “Memory Modules” on page 3-10.
Hard drive(s) May include the following internal drives:
• Up to two Ultra ATA-133 IDE hard drives
• Up to four LVD Ultra 320 SCSI hard drives with 68-pin interface
connector plus four-pin standard power connector
