3. Remove the battery from the computer (3).
To insert the battery, reverse the removal procedures.
Speakers
To remove the speakers, use this procedure and illustration.
Table
5-3 Speaker description and part number
Description Spare part number
Speaker Kit M00323-001
Before removing the speakers, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 21).
2. Remove the bottom cover (Bottom cover on page 21).
3. Remove the battery (see Battery on page 23).
Remove the speakers:
1. Disconnect the speaker cable from the system board (1).
2. Lift the plastic shield that covers the cables on the touchpad (2).
24 Chapter 5 Removal and replacement procedures for authorized service provider parts
