2. Pull the volume button into the computer to remove it (2).
Reverse this procedure to install the volume button.
Webcam privacy switch
To remove the webcam privacy switch, use this procedure and illustration.
Table
5-11 Webcam privacy switch description and part number
Description Spare part number
Webcam privacy switch M00321-001
Before removing the webcam privacy switch, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 21).
2. Remove the bottom cover (Bottom cover on page 21).
3. Disconnect the battery cable from the system board (see Battery on page 23).
4. Remove the USB board (see USB board on page 29).
Remove the webcam privacy switch:
1. Use tweezers to remove the bracket (1).
32 Chapter 5 Removal and replacement procedures for authorized service provider parts
