Table 5-12 System board descriptions and part numbers (continued)
Description Spare part
number
Intel Core i5-10210U processor, 8 GB of system memory, and 128 GB of eMMC memory (models with a ngerprint
reader)
M00303-001
Intel Core i3-10110U processor, 8 GB of system memory, and 128 GB of eMMC memory (models with a ngerprint
reader)
M00301-001
Intel Core i3-10110U processor, 8 GB of system memory, and 64 GB of eMMC memory (models without a ngerprint
reader)
M00297-001
Intel Core i3-10110U processor, 8 GB of system memory, and 64 GB of eMMC memory (models with a ngerprint
reader)
M00299-001
Intel Core i3-10110U processor, 4 GB of system memory, and 64 GB of eMMC memory (models with a ngerprint
reader)
M00298-001
Intel Pentium 6405U processor, 4 GB of system memory, and 64 GB of eMMC memory M00302-001
Before removing the system board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 21).
2. Remove the bottom cover (Bottom cover on page 21).
3. Remove the battery (see Battery on page 23).
4. Remove the fan (see Fan on page 27).
1. Disconnect the following cables from the system board:
● Antenna cables from integrated WLAN module (1)
● Camera cable (2)
● Display cable (3)
● USB board cable (ZIF) from USB board (4)
● USB board cable (ZIF) from USB board (5)
● Keyboard backlight cable (ZIF) (6) (select products only)
● Touchpad cable (ZIF) (7)
● Keyboard cable (ZIF) (8)
● Fingerprint reader cable (ZIF) (9)
● Speaker cable (10)
34 Chapter 5 Removal and replacement procedures for authorized service provider parts
