HP Compaq 6000 Pro

Webcam Module
Description Spare part number
Webcam module 625254-001
Camera to MPCA cable 643150-001
The webcam module is located at the top of the computer. It is secured with two screws and has one
connector.
Figure 7-17 Webcam module location
To remove the webcam module:
1.
Prepare the computer for disassembly (see
Preparing to Disassemble the Computer on page 43).
2. Remove the small rear cover (see
Small Rear Cover on page 44).
3.
Remove the port cover (see
Port Cover on page 45).
4. Remove the stand (see
Stand on page 46).
5. Remove the drive cover (see
Optical Drive on page 47).
6. Remove the memory cover (see
Memory on page 53).
7. Remove the rear panel (see
Upper Rear Panel on page 55).
Webcam Module
57
