HP dc5100 - Microtower PC Service & Reference Guide

Service Reference Guide, dc5100 376220-001 A–7
Connector Pin Assignments
24-Pin Power
Connector
Pin Signal Pin Signal Pin Signal Pin Signal
1
2
3
4
5
6
+3.3 V
+3.3 V
GND
+5 V
GND
+5 V
7
8
9
10
11
12
GND
POK
+5 Vaux
+12 V
+12 V
+3.3 V
13
14
15
16
17
18
+3.3 V
-12 V
GND
PSON
GND
GND
19
20
21
22
23
24
GND
open
+5 V
+5 V
+5 V
GND
24
12
13
1
24-Pin MicroFit Power
Connector
Pin Signal Pin Signal Pin Signal Pin Signal
1
2
3
4
5
6
+5 Vaux
GND
+5 V
+5 V
PS_ON
GND
7
8
9
10
11
12
PWRGD
+3.3 V
+3.3 V
Tach
GND
Fan-CMD
13
14
15
16
17
18
+12 V
+5 V Sense
GND
+5 V
+5 V
+3.3 V
19
20
21
22
23
24
GND
+3.3 Sense
+3.3 V
+3.3 V
GND
-12 V
4-Pin Power (for CPU)
Connector and Icon Pin Signal
1 GND
2 GND
3 +12 V CPU
4 -12 V CPU
24
12
13
1

HP dc5100 - Microtower PC Specifications

General

Processor	Intel Pentium 4 or Intel Celeron D
Memory	Up to 4 GB DDR2 SDRAM
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Operating System	Windows XP Professional
Optical Drive	DVD-ROM, CD-RW, or DVD+/-RW
Graphics	Intel Graphics Media Accelerator 900
Audio	Integrated audio
Expansion Slots	1 PCI Express x16, 3 PCI
Ports	1 Serial, 1 Parallel
Weight	Approx. 22 lbs (10 kg)
Processor Speed	Up to 3.8 GHz
Storage	40 GB to 250 GB HDD
