HP dc5100 - Microtower PC Service & Reference Guide

A–8 376220-001 Service Reference Guide, dc5100
Connector Pin Assignments
6-Pin Power
Connector and Icon Pin Signal
1GND
2GND
3GND
412 V CPU
512 V CPU
6+12 V
6
4
SATA Data and Power
Drive Connector
Pin Signal Pin Signal Pin Signal Pin Signal
S1
S5
Ground
B-
S2
S6
A+
B+
S3
S7
A-
Ground
S4 Ground
P1
P5
P9
P13
V 3.3
Ground
V 5
V 12
P2
P6
P10
P14
V 3.3
Ground
Ground
V 12
P3
P7
P11
P15
V 3.3
V 5
Reserved
V 12
P4
P8
P12
Ground
V 5
Ground
*S = Data, P = Power

HP dc5100 - Microtower PC Specifications

General

Processor	Intel Pentium 4 or Intel Celeron D
Memory	Up to 4 GB DDR2 SDRAM
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Operating System	Windows XP Professional
Optical Drive	DVD-ROM, CD-RW, or DVD+/-RW
Graphics	Intel Graphics Media Accelerator 900
Audio	Integrated audio
Expansion Slots	1 PCI Express x16, 3 PCI
Ports	1 Serial, 1 Parallel
Weight	Approx. 22 lbs (10 kg)
Processor Speed	Up to 3.8 GHz
Storage	40 GB to 250 GB HDD
