Operations 21
WARNING: To reduce the risk of personal injury, be careful when pressing the server rail-
release latches and sliding the server into the rack. The sliding rails could pinch your fingers.
5. After performing the installation or maintenance procedure, slide the server into the rack:
a. Slide the server fully into the rack.
b. Secure the server by tightening the thumbscrews.
6. Connect the peripheral cables and power cords.
Access the HP Systems Insight Display
To eject the HP Systems Insight Display:
1. Press and release the display.
2. Extend the display from the chassis.
The display can be rotated up to 90 degrees.
