HP DL360 User Manual

Component identification 7
Component identification
Front panel components
Item Description
1 Hard drive bay 5 (optional)*
2 Hard drive bay 6 (optional)*
3 DVD tray/hard drive bays 7 and 8 (optional)*
4 HP Systems Insight Display ("Access the HP Systems
Insight Display" on page 21)
5 Front USB connector
6 Video connector
7 Hard drive bay 4
8 Hard drive bay 3
9 Hard drive bay 2
10 Hard drive bay 1
*An optional hard drive backplane is required when the server is configured with eight hard drives.

HP DL360 Specifications

General

Processor Sockets	2
CPU	Intel Xeon Scalable
Memory	Up to 3TB DDR4
Form Factor	1U Rack
Power Supply	Redundant Power Supplies, various wattage options
Network Controller	Embedded 1Gb or 10Gb Ethernet
RAID Support	Smart Array RAID
Operating System Support	Windows Server, Linux, VMware
Storage	Up to 10 SFF SAS/SATA/NVMe drives or 4 LFF SAS/SATA drives
