Hardware options installation 60
6.
Install the expansion board into the slot until it seats firmly.
7. Install the PCI riser board assembly (on page 25).
IMPORTANT: The server does not power up if the PCI riser board assembly is not seated
properly.
NOTE: The same procedures apply for installing an expansion board in PCI expansion slot 1.
8. Connect all internal or external cabling to the expansion boards.
9. Install the access panel (on page 22).
10. Slide the server into the rack.
11. Power up the server (on page 20).
Installing a PCI-X riser board
1. Power down the server (on page 20).
2. Extend the server from the rack (on page 20).
3. Remove the access panel (on page 22).
4. Remove the PCI riser board assembly (on page 24).
5. Remove all expansion boards, if installed.

HP DL360 Specifications

General

Processor Sockets	2
CPU	Intel Xeon Scalable
Memory	Up to 3TB DDR4
Form Factor	1U Rack
Power Supply	Redundant Power Supplies, various wattage options
Network Controller	Embedded 1Gb or 10Gb Ethernet
RAID Support	Smart Array RAID
Operating System Support	Windows Server, Linux, VMware
Storage	Up to 10 SFF SAS/SATA/NVMe drives or 4 LFF SAS/SATA drives
