HP DL360 User Manual

Troubleshooting 93
General diagnosis flowchart
The General diagnosis flowchart provides a generic approach to troubleshooting. If you are unsure of the
problem, or if the other flowcharts do not fix the problem, use the following flowchart.
Item Refer to
1 "Symptom information (on page 90)"
2 "Loose connections (on page 91)"
3 "Service notifications (on page 92)"
4 The most recent version of a particular server or option firmware is
available on the HP Support website (http://www.hp.com/support
).

HP DL360 Specifications

General

Processor Sockets	2
CPU	Intel Xeon Scalable
Memory	Up to 3TB DDR4
Form Factor	1U Rack
Power Supply	Redundant Power Supplies, various wattage options
Network Controller	Embedded 1Gb or 10Gb Ethernet
RAID Support	Smart Array RAID
Operating System Support	Windows Server, Linux, VMware
Storage	Up to 10 SFF SAS/SATA/NVMe drives or 4 LFF SAS/SATA drives
