Page #34 background imageLoading...
Page #34 background image
Hardware options installation 34
Hardware options installation
Introduction
If more than one option is being installed, read the installation instructions for all the hardware options
and identify similar steps to streamline the installation process.
WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the
internal system components to cool before touching them.
CAUTION: To prevent damage to electrical components, properly ground the server before
beginning any installation procedure. Improper grounding can cause electrostatic discharge.
Processor and fan module option
Install fan 2 only when processor 2 is installed. When only one processor is installed, always install the
fan blank.
To install the component:
1. Update the system ROM.
Locate and download the latest ROM version from the HP website (http://www.hp.com/support
).
Follow the instructions on the website to update the system ROM.
2. Power down the server (on page 20).
3. Extend the server from the rack (on page 20).
4. Remove the access panel (on page 22).
5. Remove the BBWC battery pack (on page 22).
6. Remove the air baffle (on page 23).
