2–8 415606-001 Service Reference Guide, dx2200 MT
Setup Utilities and Diagnostics Features
Integrated
Peripherals
(continued)
Onboard Serial
Port
Allows you to select a setting for the onboard serial port:
•Disabled
•3F8/IRQ4
•2F8/IRQ3
•3E8/IRQ4
•2E8/IRQ3
Onboard Parallel
Port
Allows you to select a setting for the onboard parallel port:
•Disabled
• 378/IRQ7
•278/IRQ5
•3BC/IRQ7
Parallel Port Mode Allows you to select parallel port mode:
•SPP
•EPP
•ECP
•ECP+EPP
•Normal
ECP Mode Use
DMA
If Parallel Port Mode is set to ECP or ECP+EPP, allows you to set
the DMA channel for ECP Mode to 1 or 3.
Power
Management
Setup
After AC Power
Loss
Allows you to select system power loss behavior:
•On
•Off
• Last State
ACPI Suspend
Type
ACPI sleep mode is S3 (Suspend To RAM)
External Modem
S5 Wake-Up
Disables/enables wake-up modem from S5.
RTC Alarm Resume Disables/enables RTC alarm.
Date (of Month) If RTC Alarm Resume is enabled, allows you to select the day of
the month for resumption of RTC alarm. (Set to 0 for every day.)
Resume Time
(hh:mm:ss)
If RTC Alarm Resume is enabled, allows you to select what time
the RTC alarm will resume.
PnP/PCI
Configurations
Reset
Configuration
Data
Disables/enables automatic reconfiguration.
The default is Disabled. Select Enabled to reset Extended
System Configuration Data (ESCD) when you exit Setup, if you
have installed a new add-on and the system reconfiguration has
caused such a serious conflict that the OS cannot boot.
Heading Option Description
