12. A BIOS board is connected to the system board as shown in the following image. DO NOT remove this
board when removing the system board.
Reverse this procedure to replace the system board.
IMPORTANT: When installing a new system board, the thermal grease and thermal pads must be replaced.
See Heat sink on page 56 for more information.
54 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
