Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
Intel Core i5-1135G7 processor, 16 GB system RAM M46078-xx1
Intel Core i5-1135G7 processor, 16 GB system RAM (OSR) M46087-xx1
Intel Core i5-1135G7 processor, 8 GB system RAM M46079-xx1
(18) RTC battery M21797-001
(19) Speakers
For use in models without WWAN M50317-001
For use in models with WWAN M50318-001
(20) Card reader board
NOTE: The card reader board cable is available in the Cable Kit as spare part number
M03867-001.
M03883-001
(21) Bottom cover
For use on models with WWAN M46054-001
For use on models without WWAN M46055-001
Bracket Kit
To identify the Bracket Kit components, use this illustration and table.
Table
3-2 Bracket Kit component descriptions and part numbers
Item Component Spare part number
Bracket Kit, includes: M46057-001
(1) Fingerprint reader bracket
(2) USB system board bracket
(3) Solid-state drive cover
Bracket Kit 19
