Plastics Kit
To identify the Plastics Kit components, use this illustration and table.
Table 3-3 Plastics Kit component descriptions and part numbers
Item Component Spare part number
Plastics Kit, includes: M46068-001
(1) SIM card insert
(2) Fingerprint reader insert
(3) I/O system board bracket
(4) Smart card reader insert
SIM tray (not illustrated)
Smart card reader insert foil (not illustrated)
Cable Kit
To identify the contents of the Cable Kit, use this table.
Table
3-4 Cable Kit content descriptions and part number
Component Spare part number
Cable Kit, includes: M03867-001
Touchpad cable
Fingerprint reader board cable
Smart card reader cable
20 Chapter 3 Illustrated parts catalog
