3. Pull the card reader out from under the WWAN antenna holder to remove it from the computer (3).
Reverse this procedure to install the card reader board.
Keyboard with top cover
The top cover with keyboard remains after removing all other spare parts from the computer. In this section,
the rst table provides the main spare part number for the top cover/keyboards. The second table provides
the country codes.
Table
6-14 Keyboard with top cover descriptions and part numbers
Description Spare part number
Keyboard with top cover, backlit M46071-xx1
Keyboard with top cover, not backlit M46073-xx1
Keyboard with top cover, backlit, for use in privacy models M46072-xx1
Table 6-15 Spare part country codes
For use in country or
region
Spare part
number
For use in country or
region
Spare part
number
For use in country or
region
Spare part
number
Belgium -A41 Hungary -211 Saudi Arabia -171
Brazil -201 Iceland -DD1 Slovenia -BA1
Bulgaria -261 India -D61 South Korea -AD1
Chile -161 Israel -BB1 Spain -071
Czech Republic/Slovakia -FL1 Italy -061 Switzerland -BG1
Denmark -081 Japan -291 Taiwan -AB1
56 Chapter 6 Removal and replacement procedures for authorized service provider parts
