Rear panel components (ProDesk 400)
NOTE: Your computer model may look slightly dierent from the illustration in this section.
1 External Antenna Connector (optional) 8 VGA Monitor Connector
2 Thumbscrew 9 Serial Port
3 Padlock Loop 10 USB 3.0 Ports (2) (blue) with support for wake
from S4/S5 power states
4 Cable Lock Slot 11 USB 2.0 Connectors (2) (black)
5 External Antenna Connector (optional) 12 RJ-45 Network Connector
6 Wireless antenna 13 Power Connector
7 DisplayPort Monitor Connector
4 Chapter 1 Product features
