18
Figure 20 Mounting the router in the rack
Grounding the router
WARNING!
Correctly connecting the router grounding cable is crucial to lightning protection and EMI protection.
IMPORTANT:
The resistance reading should be smaller than 5 ohms between the chassis and the ground.
Grounding the router through the grounding terminal on the
rack
IMPORTANT:
Make sure the rack is reliably grounded before grounding the router.
To connect the grounding cable:
