To replace an HMIM:
1. Completely loosen the captive screws of the HMIM.
2. Gently pull the HMIM out of the slot along the slide rails.
3. Install a new HMIM. For the installation procedure, see "Installing the router."
If you do not install a new HMIM, install a filler panel and tighten the screws.
Figure 73 Pulling the HMIM out of the slot
Figure 74 Installing a filler panel
Replacing a MIM
WARNING!
You can replace a MIM when the router is powered on. However, before replacing a MIM when the
router is powered on, you must execute the remove hmimslot slotnumber command.
To replace a MIM:
1. Completely loosen the captive screws of the HMIM adapter.
2. Gently pull the MIM and the HMIM adapter out of the slot along the slide rails.
