49
Figure 67 Removing the CF card
3. Install a new CF card. For the installation procedure, see "Installing the router."
If you do not install a new CF card, close the CF card cover.
Replacing a SIC
CAUTION:
SIC interface modules are not hot swappable. Make sure the router is powered off before installing a
SIC.
To replace a SIC:
1. Completely loosen the captive screws of the SIC.
2. Gently pull the SIC out along the slide rails.
3. Install a new SIC. For the installation procedure, see "Installing the router."
If you do not install a SIC, install a filler panel and tighten the screws.
1
2
3
