Local port operation
Overview
The HPE G3 KVM Console Switch system has at least one local port (based on the specific model) on the
rear panel ("Console switch components" on page 14) that enables the user to connect a keyboard,
monitor, and mouse to the HPE G3 KVM Console Switch for direct access.
Use the Main dialog box ("Accessing the Main dialog box" on page 22) to view, configure, and control
servers in the HPE G3 KVM Console Switch system.
Accessing the Main dialog box
To access the Main dialog box, choose one of the following default key sequences.
• Print Scrn
• Ctrl + Ctrl
To configure the following additional key sequences, see "Accessing the Menu dialog box (on page 27)."
• Alt + Alt
• Shift + Shift
Press the Alt, Shift, or Ctrl key twice within one second to launch the OSD. Use this key sequence where
you see Print Scrn. For more information, see "Accessing the Menu dialog box (on page 27)."
The Main dialog box appears.
Button
Description
Clear
Clear all offline IAs
Disconnect
Disconnect the local KVM session
Setup
Access the Setup dialog box and configure the OSD
Commands
Access the Commands dialog box
