792523-001 Edition 1
Page 15
ENGLISH
ENGLISH
5. Maintenance
Battery tray removal (cont.)
C
D
Installing the new battery module
Perform the removal instructions in reverse order.
To ensure safety and high performance, only use batteries supplied by HPE
Take care to firmly press together the two parts of the connector during remounting.
5.4 Spares
Ordering Spares
To order a spare, visit the HPE website (http://www.hpe.com/info/hpparts).
To replace parts under warranty, contact an HPE authorized service
representative.
UPS spare parts list
Item Spare Part Number
SPS-UPS T750 G4 NA/JP 796774-001
SPS-UPS T750 G4 INTL 796775-001
SPS-UPS T1000 G4 NA/JP
796763-001
SPS-UPS T1000 G4 INTL 796771-001
SPS-UPS T1500 G4 NA/JP 796772-001
SPS-UPS T1500 G4 INTL
796773-001
SPS-BATTERY KIT UPS T750 796781-001
SPS-BATTERY KIT UPS T1000 796779-001
SPS-BATTERY KIT UPS T1500 796780-001
C
Remove the plastic
protection cover
in front of the battery.
D
Pull the plastic tab to
remove the battery block
and replace the block.
