Page 16
792523-001 Edition 1
ENGLISH
6. Technical Specifications
6.1 HPE T750 G4 NA/JP UPS, HPE T1000 G4 NA/JP UPS, and HPE T1500 G4 NA/JP UPS
HPE T750 G4 NA/
JP
UPS
HPE T1000 G4
NA/
JP UPS
HPE T1500 G4
NA/JP UPS
Output Power @ 120V NA: 750 VA
525W
NA: 1000 VA
700W
NA: 1440 VA
1080W
Output Power @ 110V NA: 750 VA
525W
NA: 1000 VA
700W
NA: 1440 VA
1080W
Output Power @ 100V JPN: 750 VA
500W
JPN: 1000VA
680W
JPN: 1200 VA
980W
AC Input power
Rated input voltage
Input voltage range
Single phase 100-120V
80 to 144V
Input frequency
range
45 to 55 Hz (50 Hz system), 55 to 65 Hz (60 Hz system)
Output on battery power
Voltage 100/110/120V (-10% to +5%)
(1)
Frequency 50/60 Hz ±0.1 Hz
Battery (sealed lead acid, maintenance free)
Standard
2 x 12V
7 Ah
2 x 12V
9 Ah
3 x 12V
9 Ah
Environment
Operating tempera-
ture range
0 to 35°C/32 to 95°F
Storage temperature
range
-15 to +40°C/5 to 104°F
Relative humidity
0 to 90% (without condensation)
Noise level
< 40 dBA in normal mode
(1) Adjustable to 100/110/120V, but must be set to the identical AC power source value.
Caution: To reduce the risk of re, connect only to a circuit provided with 20A maximum branch circuit overcurrent pro-
tection in accordance with the National Electric Code, ANSI/NFPA 70.
Filter
Transformer
AVR
Charger Inverter
Battery
