HP Integrity BL860c i4

Figure 2: Mixed DIMM load order
Table 7: DIMM pair load order
CPU0 CPU1
CPU0 only
1st 3A 4A — —
2nd 9B 10B — —
3rd 1C 6C — —
4th 7D 12D — —
5th 2E 5E — —
6th 8F 11F — —
Both CPUs loaded
1st 3A 4A — —
2nd — — 1A 7A
3rd 9B 10B — —
4th — — 6B 10B
5th 1C 6C — —
6th — — 3C 9C
7th 7D 12D — —
8th — — 4D 12D
Table Continued
50 Optional components
