Table 14: Indications for the iLO 3 TUI LEDs
VFP LED Purpose Equivalent Indications Value
HEALTH Represents the
health of the entire
system/partition.
Shows the worst
health case of any
blade that is part of
the partition.
System Health LED in the
iLO 3 GUI's Virtual Front
Panel
Flashing
amber
Health of the partition and the
health of one or more blades
within the partition is
DEGRADED, meaning that:
• A FRU has failed
• A fatal event has been
logged (Level seven alert
events cause this
indication if there are no
FRU failures.)
NOTE:
If the SYSTEM LED
lights red, this
counts as a FRU
failure for the
HEALTH LED.
Flashing red Health of the partition is
FATAL and the health of one
or more blades within the
partition are FATAL, meaning
that:
A FRU has failed and A fatal
event has been logged (Level
seven events cause this
indication if there are FRU
failures on one of the blades
in the partition.)
A reset will clear this LED of a
fatal event, but not a FRU
failure. A power cycle will
clear both.
Steady green All internal FRUs in the
partition are healthy, there are
no fatal events, and the
system power is on.
Off Power to the system/partition
is off and there were no
AMBER or RED HEALTH
indications on the last boot.
SYSTEM There is only one
SYSTEM LED per
partition. The state
will be the same for
System Event Log Health
as displayed on the
Flashing red There has been a FATAL
event since the last power on
or system reset.
A reset or power on will clear
this LED.
Table Continued
Troubleshooting 99
