HP J4900B - Page 35

2-15
Installing the Switch
Installation Procedures
Installing the Switch
2. Hold the switch with attached brackets up to the rack and move it
vertically until rack holes line up with the bracket holes, then insert and
tighten the four number 12-24 screws holding the brackets to the rack.
Install 12-24
screws
