HP J8697A User Manual

6-34
RADIUS Authentication, Authorization, and Accounting
Using SNMP To View and Configure Switch Authentication Features
Figure 6-13. Disabling SNMP Access to the Authentication MIB and Displaying the Result
HP Switch(config)# snmp-server mib hpswitchauthmib excluded
HP Switch(config)# show snmp-server
SNMP Communities
Community Name MIB View Write Access
-------------------- -------- ------------
public Manager Unrestricted
test Manager Unrestricted
Trap Receivers
Link-Change Traps Enabled on Ports [All] : All
Traps Category Current Status
_____________________________ __________________
SNMP Authentication : Extended
Password change : Enabled
Login failures : Enabled
Port-Security : Enabled
Authorization Server Contact : Enabled
DHCP-Snooping : Enabled
Dynamic ARP Protection : Enabled
Dynamic IP Lockdown : Enabled
Address Community Events Type Retry Timeout
---------------------- ---------------------- -------- ------ ------- ------
15.255.131.57 public None trap 3 15
192.169.1.106 public None trap 3 15
15.255.135.68 public None trap 3 15
15.255.135.235 public None trap 3 15
15.255.135.222 public None trap 3 15
Excluded MIBs
hpSwitchAuthenticationMIB
Snmp Response Pdu Source-IP Information
Selection Policy : rfc1517
Trap Pdu Source-IP Information
Selection Policy : rfc1517
Indicates that SNMP security MIB
access is disabled, which is the
nondefault setting.
This command disables
SNMP security MIB
access.

HP J8697A Specifications

General

Ports	24
Form Factor	Rack-mountable
Power Supply	Internal
Management	Managed
VLAN Support	Yes
Jumbo Frame Support	Yes
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Model	HP J8697A
Port Type	10/100/1000BASE-T
Layer	Layer 2
