HP J8697A User Manual

11-23
Configuring Advanced Threat Protection
Dynamic IP Lockdown
Monitoring Dynamic ARP Protection
When dynamic ARP protection is enabled, you can monitor and troubleshoot
the validation of ARP packets with the debug arp-protect command. Use this
command when you want to debug the following conditions:
■ The switch is dropping valid ARP packets that should be allowed.
■ The switch is allowing invalid ARP packets that should be dropped.
Figure 11-3. Example of debug arp-protect Command
Dynamic IP Lockdown
The Dynamic IP Lockdown feature is used to prevent IP source address
spoofing on a per-port and per-VLAN basis. When dynamic IP lockdown is
enabled, IP packets in VLAN traffic received on a port are forwarded only if
they contain a known source IP address and MAC address binding for the port.
The IP-to-MAC address binding can either be statically configured or learned
by the DHCP Snooping feature.
HP Switch(config)# debug arp-protect
1. ARP request is valid
"DARPP: Allow ARP request 000000-000001,10.0.0.1 for 10.0.0.2 port A1,
vlan "
2. ARP request detected with an invalid binding
"DARPP: Deny ARP request 000000-000003,10.0.0.1 port A1, vlan 1"
3. ARP response with a valid binding
"DARPP: Allow ARP reply 000000-000002,10.0.0.2 port A2, vlan 1"
4.ARP response detected with an invalid binding
"DARPP: Deny ARP reply 000000-000003,10.0.0.2 port A2, vlan 1"

HP J8697A Specifications

General

Ports	24
Form Factor	Rack-mountable
Power Supply	Internal
Management	Managed
VLAN Support	Yes
Jumbo Frame Support	Yes
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Model	HP J8697A
Port Type	10/100/1000BASE-T
Layer	Layer 2
