10-121
IPv4 Access Control Lists (ACLs)
Enable ACL “Deny” Logging
Example of Resetting ACE Hit Counters to Zero
The following example uses the counter activity in figure 10-47 (page 10-120)
to demonstrate using
clear statistics to reset the counters to zero.
Figure 10-49. Example of IPv6 ACL Performance Monitoring Output
HP Switch# show statistics aclv6 V6-02 vlan 20 vlan
HitCounts for ACL V6-02
Total
( 5) 10 permit icmp ::/0 fe80::20:2/128 128
( 4) 20 permit icmp ::/0 fe80::20:3/128 128
( 136) 30 permit tcp fe80::20:1/128 ::/0 eq 23
( 2) 40 deny icmp ::/0 fe80::20:1/128 128
( 10) 50 deny tcp ::/0 ::/0 eq 23
( 8) 60 deny icmp ::/0 ::/0 133
( 155) 70 permit ipv6 ::/0 ::/0
HP Switch# clear statistics aclv6 V6-02 vlan 20 vlan
HP Switch# show statistics aclv6 V6-02 vlan 20 vlan
HitCounts for ACL V6-02
Total
( 0) 10 permit icmp ::/0 fe80::20:2/128 128
( 0) 20 permit icmp ::/0 fe80::20:3/128 128
( 0) 30 permit tcp fe80::20:1/128 ::/0 eq 23
( 0) 40 deny icmp ::/0 fe80::20:1/128 128
( 0) 50 deny tcp ::/0 ::/0 eq 23
( 0) 60 deny icmp ::/0 ::/0 133
( 0) 70 permit ipv6 ::/0 ::/0
