HP J9146A - ProCurve Switch 2910al-24G-PoE - Page 113

Index – 5
Index
switch
connecting to a power source … 2-18
description … 1-1
downloading new software … 4-12
electrical specifications … A-1
environmental specifications … A-1, B-1
features … 1-16
front panel description … 1-4
included parts … 2-1
LED descriptions … 1-6
mounting in a rack or cabinet … 2-11
mounting on horizontal surface … 2-13
physical specifications … A-1
switch operation
verifying after installation … 2-5
Switch Setup screen
configuring a subnet mask … 3-3
configuring an IP address … 3-3
field descriptions … 3-3
switch setup screen … 3-2
T
technology distance specifications … C-3
telnet access to the console … 3-5
Temp Status LED … 2-20, 2-23
terminal configuration … 2-25
Test LED
behavior during self test … 2-7
testing
checking the console messages … 4-9
checking the LEDs … 4-9
diagnostic tests … 4-9
end-to-end communications … 4-10
link test … 4-10
Ping test … 4-10
switch operation … 4-9
switch-to-device communications … 4-10
twisted-pair cabling … 4-10
tips for troubleshooting … 4-1
topologies
effects of improper topology … 4-2
samples of … 2-29
transceiver
install or remove … 2-14
transceivers SFP+ … 1-2
troubleshooting … 4-1
basic tips … 4-1
checking port configuration … 4-3
checking the console messages … 4-9
checking the LEDs … 4-9
common network problems … 4-1
connecting to fixed full-duplex devices … 4-1
diagnostic tests … 4-9
effects of improper topology … 4-2
effects of non-standard cables … 4-2
link test … 4-10
Ping test … 4-10
Proactive Network tools … 4-8
restoring factory default configuration … 4-11
testing connections to other devices … 4-10
testing end-to-end communications … 4-10
testing the switch … 4-9
testing the twisted-pair cables … 4-10
twisted-pair cable
cross-over cable pin-out … C-8
pin-outs … C-6–C-7, C-9
straight-through cable pin-out … C-7, C-9
switch-to-computer connection … C-7, C-9
switch-to-switch or hub connection … C-8
testing … 4-10
twisted-pair ports
HP Auto-MDIX feature … C-6
U
Usr LEDs … 1-7
V
voltage ranges … 2-6
VT-100 terminal
serial cable connection for … 2-25
W
wiring rules for twisted-pair cables … C-6
