HP J9146A - ProCurve Switch 2910al-24G-PoE - Module Specifications; Physical; Environmental

B-1
Module Specifications
Module Specifications
B
Module Specifications
Physical
Environmental
Optical Power Specifications
See the tranceiver specifications which is on the ProCurve Website at
www.hp.com/go/procurve/faqs, go to "ProCurve Mini-GBICs and Transceivers"
and click on "ProCurve 10-GbE transceivers" and go to Specifications.
Modules
Width: 106.17 mm (4.18 in)
Depth: 104.39 mm (4.11 in)
Height: 35.56 mm (1.40 in)
Weight: 0.159 kg (.35 lbs)
MODULE
Operating Non-Operating
Temperature: 0C to 55C (32F to 131F) -40C to 70C (-40F to 158F)
Relative humidity:
(non-condensing)
15% to 95% at 40C (104F) 15% to 90% at 65C (149F)
Maximum altitude: 3.0 Km (10,000 ft) 4.6 Km (15,000 ft)
